PRODUCT

EtherCAT I/O system
EtherCAT Plug-in Modules for Wind Industry

The EtherCAT plug-in modules from the EJ series minimize space requirements and wiring effort in
wind turbines.

In the displayed control cabinet, the I/O level is realized enables them to be plugged directly into an application-
with the EtherCAT plug-in modules and a highly compact, specific signal distribution board which distributes the
application-specific signal distribution board with a signals and the power supply to individual application-
wiring level from stock and pre-assembled cables. The specific connectors, in order to connect the controller to
EtherCAT plug-in modules are based electronically on the further system modules. Elaborate manual wiring of single
well-known EtherCAT I/O Terminals and offer the same wires is replaced by simply plugging in prefabricated cable
broad variety of signals. Their electromechanical design harnesses. Many of the other components that would
otherwise be installed separately in the control cabinet
are housed as compact plug-in modules on the board, e.g.
relays, fuses or surge voltage protection equipment. This
means that the space requirement in the control cabinet
is significantly reduced, particularly in series production
with mid to high quantities, also lowering costs. Another
crucial advantage is the minimized risk of incorrect wiring.
Beckhoff has a broad portfolio of PC-based control
technology. Here its focus is on the ongoing integration
Source: Beckhoff Automation Pvt Ltd operational management to pitch control; converter,
of all plant and system functions: everything from
gear unit, and brake control; wind farm networking;
and hydrogen technology as a bridging technology to
energy storage.

The EtherCAT plug-in modules and the plug level for sensors and actuators can be placed Beckhoff Automation Pvt Ltd
E: info@beckhoff.co.in
flexibly on the signal distribution board. The development of a signal distribution board www.beckhoff.com/ethercat-plug-in-modules
is carried out by the user or as a service by Beckhoff.
